The KST15000 crawler undercarriage is designed for tracked equipment requiring a 15,000 kg load capacity and stable low-speed travel. The complete undercarriage integrates the track system, drive components and structural frame into a compact solution for heavy-duty mobile machinery.
With a unit weight of approximately 3,300 kg, a maximum travel speed of 0.46 km/h and a maximum gradeability of 20°, the KST15000 is suitable for applications where high load capacity, traction and controlled movement are required.
The KST15000 can be used as a crawler running system for heavy-duty tracked equipment and specialized mobile machinery.
Heavy-duty tracked machinery
Mining and material handling equipment
Construction machinery
Specialized crawler equipment
Conveyor and mobile industrial equipment
The KST15000 is rated for a load capacity of up to 15,000 kg, making it suitable for heavy equipment and application-specific crawler systems.
A traction force of 115 kN provides the pulling capability required for controlled movement of heavy tracked equipment.
The specified travel speed is 0.46 km/h, supporting controlled movement in heavy-duty operating conditions.
Crawler undercarriages can be configured according to machine dimensions, load requirements, mounting conditions, drive system and operating environment.
| Specification | KST15000 |
|---|---|
| Load Capacity | 15,000 kg |
| Unit Weight | 3,300 kg |
| Traction Force | 115 kN |
| Travel Speed | 0.46 km/h |
| Ground Pressure | 61 kPa |
| Maximum Gradeability | 20° |
| Drive System | Hydraulic drive |
| Warranty | 12 months |
The following specifications are provided for the KST15000 crawler undercarriage configuration.
| Parameter | Specification |
|---|---|
| Model | KST15000 |
| Motor Displacement | 4 ml/r |
| Reduction Ratio | 1:624 |
| Traction Force | 115 kN |
| Travel Speed | 0.46 km/h |
| Ground Pressure | 61 kPa |
| Maximum Gradeability | 20° |
| Unit Weight | 3,300 kg |
| Load Capacity | 15,000 kg |
Payment: 30% deposit and 70% before shipment. T/T is generally accepted, with other payment terms subject to negotiation.
Delivery: Approximately 20–25 days after receipt of payment, subject to product configuration and order quantity.
Service: 24-hour online support and technical overseas service are available.
The crawler undercarriage is prepared for export transportation with packaging suitable for international handling and shipment.
The KST15000 has a rated load capacity of 15,000 kg, or 15 tons.
The KST15000 is suitable for tracked construction equipment, mining and material handling machinery, specialized crawler equipment and other heavy-duty mobile applications.
Yes. Crawler undercarriages can be configured according to equipment dimensions, load capacity, mounting requirements, track width, drive system and operating conditions.
The specified KST15000 configuration has a travel speed of 0.46 km/h.
The specified maximum gradeability is 20 degrees.
The standard warranty period is 12 months, subject to the applicable sales and warranty terms.
The minimum order quantity is 1 set.
